|Table Size:||15.7” x 22.0” (400 x 560mm)|
|Travel (X, Y, Z):||
23.6” x 20.1” x 20.1”
(1,020 x 510 x 510mm)
|Spindle Taper:||NST No. 40|
|Tool Storage Capacity:||40 Pcs.|
|Tool Change Time (T-T/C-C):||2.2 Sec. /4.2 Sec.|
|Rapid Feed (X, Y x Z):||2,047ipm (52m/min) X/Y x 1,890ipm (48m/min) Z|
• Ideal for machining small to medium sized work pieces
• Standard 2-station, factory installed 180 degree rotating APC. Uniquely compact design.
• Heavily ribbed stiff cast Meehanite C-Frame construction
• #40, 41HP, high speed 15,000rpm built-in spindle offers high speeds and heavy duty cutting capabilities
• Standard scraper type chip conveyor can be installed on either the right or left-hand side of the machine
• Standard 40-Tool ATC
• Operator friendly Kitamura Arumatik-Jr. CNC controller offers up to 16x faster processing speeds!
